| Selling Units | Single item | Single package size | 380X150X150 cm |
| Single gross weight | 9000.000 kg |
| Brand Name | Beilite | Suitable Excavator(ton) | 60-90t |
| Place of Origin | Zhejiang, China | Warranty | 6 month |
| Weight | 7052 kg | Core Components | Pump |
| Color | White | Video outgoing-inspection | Provided |
| Machinery Test Report | Provided | OEM/ODM | Yes |
| Suitable Excavator(ton) | 60-90t | Working Flow(l/min) | 340-400 |
| Setting pressure(bar) | 330 | Working pressure(bar) | 280-300 |
| Impact frequency(bpm) | 90-120 | Chisel Diameter (mm) | 210 |
| Rear cylinder pressure(bar) | 32-35 | Accumulator pressure(bar) | 75-80 |
| Noise level(m) | 50-55 |
| Parameter | Unit | BLTB-40 | BLTB-45 | BLTB-53 | BLTB-60 | BLTB-70 | BLTB-75 | BLTB-85 | BLTB-100 |
| Silent Type Total Weight | kg | 86 | 137 | 180 | |||||
| Top Type Total Weight | kg | 90 | 118 | 173 | |||||
| Side Type Total Weight | kg | 80 | 105 | 161 | |||||
| Silent Type Length (excl. chisel) | mm | 848 | 993 | 1126 | |||||
| Silent Type Total Length | mm | 1115 | 1330 | 1446 | |||||
| Top Type Total Length | mm | 1171 | 1294 | 1089 | |||||
| Side Type Length (excl. chisel) | mm | 655 | 745 | 1436 | |||||
| Side Type Total Length | mm | 952 | 1122 | 823 | |||||
| Silent Type Total Height | mm | 257 | 225 | ||||||
| Top Type Total Height | mm | 223 | 223 | ||||||
| Side Type Total Height | mm | 463 | 403 | ||||||
| Core Length (with chisel) | mm | 952 | 1071 | ||||||
| Core Length (without chisel) | mm | 655 | 745 | ||||||
| Chisel Diameter | mm | 40 | 45 | ||||||
| Chisel Length | mm | 450 | 500 | ||||||
| Suitable Host (Excavator) | t | 0.5~1.2 | 0.8~1.5 | ||||||
| Working Flow | l/min | 15~30 | 20~40 | ||||||
| Setting Pressure | bar | 130 | 140 | ||||||
| Working Pressure | bar | 90~120 | 90~120 | ||||||
| Impact Frequency | bpm | 800~1400 | 700~1200 | ||||||
| Impact Energy | J | 130 | 250 | ||||||
| Oil Pipe Size | inch | 1/2 | 1/2 | ||||||
| Rear Cylinder Pressure | bar | 14~17 | 14~17 | ||||||
| Accumulator Pressure | bar | / | / | ||||||
| Noise Level | m | 2~5 | 3~6 | ||||||
| Noise Decibel | dB | 74 | 75.6 | ||||||
| Suitable Host | t |
